In-screed cable DIY Kit
This system is designed to be tied down to wire mesh giving you flexibility for areas that have an irregular shape.
For installation with a 20mm - 70mm screed at 20 watts per linear metre, twin core cable.
Our heating cables are approved to Australian Electrical Standards - AS3000, Certificate Number CS8832/1.
All prices quoted include GST, mesh, cable ties, alarm and electronic programmable thermostat.
Free delivery
To your door in 2 to 4 days
In-screed cable kit inclusions
Each kit contains
Floor Heating Cable
50x50mm galvanised wire mesh
Standard Touch Screen Thermostat
Floor Heating Sensor
Cable Alarm
Detailed Installation Instructions
10 Year Cable Warranty
Standard touch screen thermostat
Thermostat features
Programable 7 Day 24 Hour
Floor or Air Sensing
2 programming mode options
Slimline design
Blue back light when operating
Responsive digital touchscreen
Thermostat maximum load is 16 amps / 3700 watts.
2 year warranty
Choose your kit size
Max output watts | Cable length (mtrs) | Coverage (sqm) Bathrooms @200w per sqm | Coverage (sqm) Large areas @150w per sqm | Kit Price |
|---|---|---|---|---|
200 | 10 | 1.0 | 1.3 | $448.91 |
240 | 12 | 1.2 | 1.6 | $467.06 |
300 | 15 | 1.5 | 2 | $527.56 |
400 | 20 | 2.0 | 2.6 | $560.23 |
500 | 25 | 2.5 | 3.3 | $579.59 |
600 | 30 | 3.0 | 4.0 | $617.10 |
700 | 35 | 3.5 | 4.6 | $653.40 |
800 | 40 | 4.0 | 5.3 | $710.27 |
900 | 45 | 4.5 | 6.0 | $746.57 |
1000 | 50 | 5.0 | 6.6 | $784.08 |
1200 | 60 | 6.0 | 8.0 | $839.74 |
1400 | 70 | 7.0 | 9.3 | $877.25 |
1600 | 80 | 8.0 | 10.6 | $952.27 |
2000 | 100 | 10.0 | 13.3 | $1082.95 |
2400 | 120 | 12.0 | 16.0 | $1287.44 |
3000 | 150 | 15.0 | 20.0 | $1370.93 |
Inscreed Cable
Installation Instructions
Download the DIY Floor
Heating Brochure
Download the Timer and Thermostat Brochure
Optional Thermostats
For a small additional cost, you can swap out the above standard thermostat for one of the options below.
Thermostats (excluding DIN Rail) are available as horizontal or vertical.
Prices listed are vertical
Glass Front ThermostatGTSW-TH-V
+ $35 Incl GST
Or purchase separately for $235 incl GST
Suitable for lighting, fans & heated towel rails
Features
Programming instructions for GTSW-TH-V thermostat
Dual Thermostat / Timer TS8100W-TH/TIM-DUAL
+ $35 Incl GST
Or purchase separately for $235 incl GST
2 in 1 Timer for your heated towel rail and control for your under floor heating
Features
Programming instructions TS8100W-TH/TIM-DUAL-V therm / timer
DEVIreg 330 DINrail 5 to 45c
+ $10 Incl GST
Or purchase separately for $206 incl GST
